Detailed Product Description
Brand: ODM Model: Off Line AOI
Testing Speed: For Each 0201 Chip <8ms Min Components: 01005 Components
Position Accuracy: <25um Moving Speed: 600mm/S (MAX)
Operation System: Microsoft Windows XP Mark Recognition Speed: 0.35S/PCS
Display: 22 "LED Display Dimensions: 860mm*960 Mm*1560 Mm
Weight: About 500 KG
High Light:

smt equipment

,

surface mount machine

Specification of 2D AOI Offline machine



A:Its suitable for AOI detection of high-end electornic products in SMT production line, and its minumum inspection compnents of 01005;



B:Its suitable for  the accurate and stable AOI detection of FPC soft board;



C: With Intelligent camera bar code identification system(optional identification of one -dimensional code and two-dimensional code);



D:Professional SPC report analysis system, monitor and anlyze product quality status at all times;



E:The fucntion of remote programming and debugging control is more powerful;



F:Automatic identification of board A and B.



Category project specifications
Visual identity system
Discriminant method Combined with weights imaging data difference analysis technology, color image contrast and color extraction analysis technology, the similarity, binary, OCR/OCV, distribution test and so on many kinds of algorithm comprehensive application
camera CCD color camera resolution: 10 micro/point
Light source RGB LED light source annular structure
Image processing speed 0201 components <8 ms
Every picture processing time < 100 ms
Testing content The printing Whether, skewed, tin much less tin, open circuit, pollution
Parts defects Lack of parts, migration, askew, made a, side made, turn over the pieces, polarity, wrong pieces, the damage
Solder defects Tin much, tin tin, even less
Wave soldering detection Little tin, tin, and solder bridge or even a short circuit, virtual welding, empty
Anti-static measures Antistatic socket, match anti-static ring
Mechanical system
PCB size 25 mm × 25 mm to 380 mm x 480 mm (can be based on customers' specific requirements custom-made more specifications)
PCB thickness 0.5 mm ~2.5 mm
PCB Warping degrees <2 mm (a fixture auxiliary rectify deformation) (special request, you can custom)
Parts height <30mm
Minimum parts 01005 chip
X,Y platform Drive equipment Ac servo motor system
Accurate location <25 μm
Movement speed 600 mm/SEC (MAX)
Software system
Operating system

support Microsoft Windows XP,Windows 2000,

Windows 2300 ,Windows 7

Recognition control system characteristics Application right value image difference modeling technology and unique color, extraction analysis technology, the study ok samples, automatic establish standard images, identification data and error threshold
operation The graphic programming, bring their own database, according to component shape automatically choose the standard test box, precise automatic positioning, micron a tuning, process and quick
Mark points Can choose two commonly used Mark points, more than-Mark function
Recognition rate 0.35 seconds/pcs
Control system
Computer host E5500,Dual Core Processor 3.0G,DDR4G,SSD60G
display 22 "LED display
Other parameters
Mechanical shape dimension(L*W*H) 860mm×960 mm×1560 mm
weight About 480 kg
power Ac 220 v plus or minus 10%, frequency 50/60 Hz, rated power 2.0 KW
Bring their own UPS



Details Of Internal  AOI
